Square Bottom Paper Bag Machine

Bag delivery unit

Bag delivery unit

Bag Bottom Forming

Bag Bottom Forming

Tube Forming

Tube Forming

Handle Pasting Station

Handle Pasting Station

Handle Forming Station with glue system

Handle Forming Station with glue system

Digital Web Guide

Digital Web Guide

Reel Unwinding Station

Reel Unwinding Station

Unwinding Station for Handle

Unwinding Station for Handle
  • Meter logo Speed* 150 Bags/Minute

Square Bottom Paper Bag Machine

  • Zest RB360 I Zest RB360 T

Square Bottom Paper Bag machine Zest RB360 includes Unwinding station, Side sealing frame component, tube forming component, bag bottom forming component & bag collection delivery unit & Control components.
Square Bottom Paper Bag machine with twisted handle Zest RB360 T includes Unwinding station for handle reel, handle forming station with hot and cold glue system, unwinding station for bag reel, handle pasting station with side sealing components, tube forming component, bag bottom forming component & bag collection delivery unit & Control components.

Paper Bag Manufacturer & Traders Needing
  • High quality end product
  • High level of automation
  • Widest bag size range
  • Suitable for small paper bags with handles
  • Automatic glue dispensing system
  • Easy tube forming system
  • Print mark sensing system
  • Specially designed for FMCG sector
  • Diamond Bottom Shape
  • Thumb Notch ( for Zest RB360 )

Technical Specification

Model Zest RB360 Zest RB360 T
Speed* (bags/minute) 150 150
Reel Width (mm) 420 to 1150  610 to 1150
Reel Diameter (mm) 1200 1200
Reel Weight (Kgs.) 1100 1100
Paper Reel Core ID (mm) 70 to 110  70 to 110
Bag Width (mm) 125 to 360  210 to 360
Bag Tube Length (mm) 270 to 530  270 to 410
Bag Bottom Size (mm) 70 to 200 80 to 200
Bag Paper GSM 80 to 170 80 to 170
Handle Rope Height (mm) - - - -  110 to 120
Handle Rope Diameter (mm) - - - -  4 to 6
Handle Patch Width (mm) - - - -  40 to 50
Handle Patch Length (mm) - - - -  152.4
Handle Paper Roll Width (mm) - - - -  80 to 100
Handle Paper Roll Diameter (mm) - - - -  1200
Handle Paper GSM - - - -  100 to 250
*Machine speed depends on paper GSM, BF of paper, type & quality of paper, size of bag, tube length of the bag, operator’s efficiency and various other factors.
